BOSCH 1928405763
概述
Product information
| part designation (long form) | wiring harness connector 26-way |
| part number | 1 928 405 763 |
| offer drawing (part) | 1 928 A00 508 |
| technical customer documentation | 1 928 A01 90T |
| assembly instruction | 1 928 A01 55M |
| final check instruction | 1 928 A00 19E |
Technical information
| packing unit | 280 pc. |
| minimum order quantity | 3080 pc. |
| time of delivery | on request |
| number of positions | 26 |
| colour | black |
| code | 1 |
| cable exit direction (KR) | straight |
| secondary locking | integrated secondary locking |
| terminal type | BTC 1.5 / BTC 2.8 / BTC 4.8 |
| type of seal (connector) | Radial seal |
| type of seal (cable) | Single wire seal |
| type of locking mechanism (connector) | Lever |
| length | 62 mm |
| width | 33 mm |
| height | 31 mm |
| temperature range, min. | -40 °C |
| temperature range, max. | 125 °C |
| scope of application | body attachment |
